• Visio like flowchart diagragramming editor
• Antialised 2D ocx activex control diagramming graphics
• flowchart Alpha channel support
• Free rotation support ActiveX Control
• Shape grouping support ActiveX OCX Control
• Very easy to use diagramming shape connection
• Show and snap to grid support
• Good blocks collection
• Rulers on different unit
• Print preview flowchart diagramming component
• Clipboard support - Copy/Paste/Cut operations;
• Multilevel Undo/Redo support activex control;
• Host ActiveX controls in diagram nodes;
• Container nodes that can hold other nodes;
• Arrow routing for avoiding crossing nodes;
• Plugins for shape libraries;
• XML Loading and Saving
• SVG Importing and Exporting.
• Auto CAD DXF Importing and Exporting.
• ArcGIS Map file (Shape file) Importing.
• More than 1,000 printer drivers.
• Compatible with All Visual Studios (From Visual Studio 6.0 to Visual Studio 2013).
• Support all Windows (32 bits, 64 bits).
• Layered graph layout;

The leader in visualization component -- FULL VC++ Source Code Shipped!

E-XD++ Diagrammer Suite is the the world’s leading VC++ and .NET visualization component. Renowned for incredibly rich graphics, XD++ helps thousands developers build applications that offer unparalleled functionality. Outstanding productivity lowers project risk and reduces maintenance headaches. With 20 years of dedicated research and development, UCanCode leads the market for visualization technologies, providing outstanding customer support.

Powerful, flexible, and easy to use Diagram Components.
Powerful and flexible enough to create diagrams exactly the way you want them to appear. So easy to use that you will be able to prototype your application in just a few minutes.

Feature rich.
With features such as automatic layout, multiple layers, collapsible sub-graphs, snap-to connection points, XML, SVG, and more, E-XD++ Have the power and flexibility you need to create sophisticated diagrams, quickly and easily. Events such as click, double-click, hover, select, rubber-band select, copy, delete, resize and move are supported. Operations such as drag-and-drop, unlimited undo/redo, and clipboard operations are common and complex, and are expected by today's sophisticated users. it full supports importing ArcGis, SVG and DXF File format.

Performance and Scalability.
UCanCode E-XD++ Capable of handling many thousands of nodes and edges, up to hundreds of thousands depending upon the complexity of the nodes you wish to draw and the operations you wish to allow. Our graphical classes are extremely lightweight objects enabling outstanding performance.

Save Time and Money and gain Reliability.
A diagram is worth 1,000 words, and E-XD++ is shipped with more than 500,000 lines of well designed and well tested code! It is used by hundreds of the world's most quality conscious companies. It will saves you thousands of hours of complex coding and years of maintenance.

Product Tour E-XD++ and UCCDraw product walkthrough
